3 Ton Diesel Electric LPG Forklift Truck with Different Attachments
3 Ton Diesel Electric LPG Forklift Truck with Different Attachments
3 Ton Diesel Electric LPG Forklift Truck with Different Attachments
3 Ton Diesel Electric LPG Forklift Truck with Different Attachments
3 Ton Diesel Electric LPG Forklift Truck with Different Attachments
1 / 5
3 Ton Diesel Electric LPG Forklift Truck with Different Attachments
3 Ton Diesel Electric LPG Forklift Truck with Different Attachments
3 Ton Diesel Electric LPG Forklift Truck with Different Attachments
3 Ton Diesel Electric LPG Forklift Truck with Different Attachments
3 Ton Diesel Electric LPG Forklift Truck with Different Attachments

3 Ton Diesel Electric LPG Forklift Truck with Different Attachments

Customization: Available
Warranty: One Year
Cab Location: Adjustable
Send Inquiry

Product Description

!
Basic Information
Model NO.
CPC-30
Type
Diesel Forklift
Power
Diesel Engine
Load Capacity
1T - 5T
Fuel
Diesel
Load Center
500mm
Lift Height
3000~5000mm
Condition
New
Delivery Time
15 Days
Engine
Xinchai
Weight
4230kg
Color
Customized
Specification
2750*1225*2070mm
Trademark
QDHZ
Diesel Forklift Truck Performance
Forklift Truck Attachments Display
⚙
Performance Parameters
Category & Item Unit CPC30 (3.0 Tons) CPC35 (3.5 Tons)
General Rated Load Capacity kg 3000 3500
Load Center mm 500 500
Power Type - Diesel Diesel
Tyre Type - Pneumatic tyre Pneumatic tyre
Dimensions Rated Lift Height mm 3000 3000
Fork Size (L*W*T) mm 1070*122*45 1070*122*50
Overall Width mm 1225 1225
Min. Turning Radius mm 2515 2515
Overhead Guard Height mm 2170 2170
Performance Travel Speed (Full Load) km/h 20 20
Lifting Speed (Full Load) mm/s 500 500
Max. Gradeability % 20 20
Engine Manufacturer - Xinchai/Quanchai Xinchai/Quanchai
Rated Power kw 36.8 36.8
Rated Speed rpm 2500 2500
?
Frequently Asked Questions
What is the standard load capacity for the CPC-30 model?
The CPC-30 model is designed for a rated load capacity of 3000kg (3 Tons), with the H series range covering requirements from 1T up to 5T.
What engine options are available for these diesel forklifts?
The standard configuration features high-performance Xinchai or Quanchai engines, specifically models like the 4D27G31, known for reliability and efficiency.
Can the mast height be customized?
Yes, while the standard lift height is 3000mm, we offer optional configurations ranging from 3000mm up to 5000mm, including three-stage masts for special requirements.
What is the typical delivery time for an order?
The standard delivery time is approximately 15 days, depending on the specific customization requirements and order volume.
What optional attachments can be added to the forklift?
We provide various options including solid tires, side shifts, different fork lengths, and multiple stage masts to suit different industrial applications.
What are the safety features included?
The forklift comes equipped with a robust overhead guard (height 2170mm), a hydraulic foot brake system, and ergonomic seat design to ensure operator safety and comfort.
